The 2U “S” Pultec – extra peak frequencies and two high shelf boost curves. The Pultec EQP-1S3 has the same wide-bandwidth tube line amp as the EQP-1A3, with modified low-frequency curves, two extra peak boost frequencies (1k and 2k) and two high-frequency shelf boost curves (5k and 10k). Pulse Techniques now builds it with a 16 kHz peak instead of the original 6 kHz, as customers asked.
Why customers choose it
Who it is for
Mixing and mastering engineers who want the widest choice of Pultec curves in a 2U tube unit.
Specifications
| Type | Program Equalizer |
|---|---|
| Amplifier | Tube |
| Format | 2U / 19 in |
| Low shelf boost | 30, 40, 70, 100 Hz shelf boost, 0 – 13.5 dB |
| Low shelf cut | 30, 40, 70, 100 Hz shelf attenuate, 0 – 17.5 dB |
| High peak boost | 1, 2, 3, 4, 5, 8, 10, 12, 16 kHz peak boost, 0 – 18 dB; 5, 10 kHz shelf boost, 0 – 14 dB |
| High shelf cut | 5, 10, 20 kHz shelf attenuate, 0 – 16 dB |
| Input Impedance | ~600 Ohms |
| Output Impedance | ~50 Ohms |
| Noise | 92 dB below +10 dBm |
| Distortion | ≤ 0.15% at +10 dBm into 600 Ohms |
| Amplifier response | Flat, 20 Hz to 20 kHz, +/- 0.5 dB |
| Tubes | 1 ea 12AU7, 12AX7, 6X4 |
| Finish | Pultec blue |
| Built | By hand, to order, in Fort Collins, Colorado |
Good to know
- Rack-mount unit for a standard 19-inch rack.
- Hand-built to order by Pulse Techniques in Fort Collins, Colorado.
