The Pultec program EQ in a space-saving 2U rack – same parts, same specs as the EQP-1A. The Pultec EQP-1A3 is the 2U (3.5-inch) version of the 3U EQP-1A, introduced in 1971 when the controls were rearranged to save rack space – “same parts, same specs”. It was the first unit Pulse Techniques brought back into production; New York’s Power Station once had 24 in each control room.
Why customers choose it
Who it is for
Studios short on rack space, mixing engineers and producers who want classic Pultec lows and highs on tracks and the mix bus.
Specifications
| Type | Program Equalizer |
|---|---|
| Amplifier | Tube |
| Format | 2U / 19 in |
| Low shelf boost | 20, 30, 60, 100 Hz shelf boost, 0 – 13.5 dB |
| Low shelf cut | 20, 30, 60, 100 Hz shelf attenuate, 0 – 17.5 dB |
| High peak boost | 3, 4, 5, 8, 10, 12, 16 kHz peak boost, 0 – 18 dB |
| High shelf cut | 5, 10, 20 kHz shelf attenuate, 0 – 16 dB |
| Input Impedance | ~600 Ohms |
| Output Impedance | ~50 Ohms |
| Noise | 92 dB below +10 dBm |
| Distortion | ≤ 0.15% at +10 dBm into 600 Ohms |
| Amplifier response | Flat, 20 Hz to 20 kHz, +/- 0.5 dB |
| Tubes | 1 ea 12AU7, 12AX7, 6X4 |
| Finish | Brushed aluminium |
| Built | By hand, to order, in Fort Collins, Colorado |
Good to know
- Rack-mount unit for a standard 19-inch rack.
- Hand-built to order by Pulse Techniques in Fort Collins, Colorado.
