A compact Pultec with EQP-1A low end – many engineers find it more transparent. The Pultec EQH-2 was first introduced in 1956 as a compact option to the EQP-1. Its low-frequency boost and cut curves are identical to the EQP-1A, with comparable high peak frequencies, a fixed-bandwidth high peak and a fixed 10 kHz high cut. It uses the same minimalist class A tube output stage as the MEQ-5.
Why customers choose it
Who it is for
Engineers who want Pultec low end with a simpler, more transparent high section – on bass, kick, vocals and acoustic instruments.
Specifications
| Type | Program Equalizer |
|---|---|
| Amplifier | Tube |
| Low shelf boost | 20, 30, 60, 100 Hz shelf boost, 0 – 13.5 dB |
| Low shelf cut | 20, 30, 60, 100 Hz shelf attenuate, 0 – 17.5 dB |
| High peak boost | 3, 5, 8, 10, 12 kHz peak boost, 0 – 18 dB |
| High shelf cut | 10 kHz shelf attenuate, 0 – 16 dB |
| Input Transformer | 600 Ohms |
| Output Transformer | 600 Ohms |
| Noise | Below -75 dBm |
| Distortion | ≤ 0.15% at +10 dBm into 600 Ohms |
| Amplifier response | Flat, 20 Hz to 20 kHz, +0 / -1 dB, ref 1 kHz |
| Tubes | 1 ea 12AX7, 6AQ5, 6X4 |
| Finish | Pultec blue |
| Built | By hand, to order, in Fort Collins, Colorado |
Good to know
- Rack-mount unit for a standard 19-inch rack.
- Hand-built to order by Pulse Techniques in Fort Collins, Colorado.
