32 preamps and 40 channels in two rack spaces. The PreSonus StudioLive 32R is a Series III digital rack mixer with 32 XMAX mic/line inputs in two rack spaces. Mix it from a laptop or tablet, or use it as a stage box or monitor mixer with a StudioLive Series III console.
Why customers choose it
Who it is for
Bands with in-ear rigs, churches, schools, small venues and installers who want a compact digital mixer controlled from a tablet.
Specifications
| Mix Channels | 40 |
|---|---|
| Mic Inputs | 32 XMAX, locking XLR/TRS combo |
| Mix Buses | 16 FlexMixes, 4 FX buses, stereo main |
| DCAs | 24 |
| USB Recording | 128 channels, USB 2.0 Type-B |
| Networking | AVB (locking etherCON), RJ-45 control port |
| Mic Gain Range | 0 to 60 dB |
| Phantom Power | +48 V |
| Headphone Output | 100 mW per channel at 60 ohm |
| Latency | 1.9 ms (analog in to out, all processing) |
| Sample Rate | 44.1, 48 kHz |
| Power Consumption | 35 W continuous |
| Size (W x H x D) | 483 x 90 x 305 mm |
| Weight | 5 kg |
| Type | Digital Rack Mixer |
| Colour | Black |
Good to know
- Needs a computer, tablet or StudioLive Series III console to control it.
- Dante is possible through the optional AVB-D16 bridge.
- Includes Capture multitrack and a Fender Studio Pro licence.
FAQ
Do I need a separate stage box?
No – the inputs are on the mixer, so you can put it on stage and mix from a tablet.
