A compact 6-channel mixer with effects. The Proel MQ6FX – mq12usb additional features include an usb audio i/o interface and extended mixing capability with monitor send, stereo group bus and 45mm control faders.. The top-of-the-line MQ16USB feature 16 inputs and 12 microphone channels together with sweep mids and one-knob intelligent COMPRESSORS on mono channels, 4 AUX sends, STEREO GROUP bus and 60mm control faders.
Why customers choose it
Who it is for
Bands, churches, schools, small events, podcasters and home studios that need a compact, reliable mixer.
Specifications
| Mono input channel – Mic Input sensitivity | from -10 to -50 dB, Balanced XLR-F |
|---|---|
| Mono input channel – Mic Input impedance | 2 Kohm |
| Mono input channel – Line Input sensitivity | from +20 to -20 dB, Balanced JACK |
| Mono input channel – Line Input impedance | 10 Kohm |
| Mono input channel – Lo cut | 75Hz, 18dB/oct. |
| Mono input channel – EQ HIGH (shelving) | ±15 dB @ 12KHz |
| Mono input channel – EQ LOW (shelving) | ±15 dB @ 80Hz |
| Stereo input channel – Line Input sensitivity | -10 dB, Balanced JACK |
| Stereo input channel – Line Input impedance | 10 Kohm |
| Master section – MAIN MIX nom. out level | +4 dBu, Balanced JACK and XLR-M |
| Master section – HEADPHONES min. impedance | 32 ohm |
| Master section – HEADPHONES max. out level | (2x) 193 mW, Stereo JACK |
| Digital effect processor – Effects | 16 presets |
| Digital effect processor – A/D and D/A converters | 24 bit |
| Digital effect processor – DSP resolution | 24 bit |
| Digital effect processor – Controls | ROTARY SELECTOR, PEAK LED, MUTE switch |
| Maximum level all outputs | +22 dBu |
| Crosstalk meas. at 1 KHz | > 82 dBu |
| HUM & Noise unweighted | < -93 dBu |
| THD + Noise at +4dB, 1kHz | < 0,008 % |
| Dimensions (WxHxD) | 162 x 210 x 51 mm |
| Weight | 1,00 kg |
| Power requirements – Supply | 18 VAC 1000 mA – use only supplied AC/AC ADAPTER |
| Power requirements – Mains Supply Voltage | 110-120 VAC (±10%) 50 / 60 Hz (US plug) |
| POWER REQUIREMENTS | 230-240 VAC (±10%) 50 / 60 Hz (EU plug) |
| POWER REQUIREMENTS | 240 VAC (±10%) 50 / 60 Hz (UK plug) |
| Power requirements – Consumption | 34 W |
