| Product Type: | Installation Loudspeakers |
|---|---|
| Type: | Wall-mounted Loudspeaker |
| Low/mid Woofer dimensions | 8 " |
| Woofer dimensions (mm) | 203 mm |
| Woofer magnet | Ferrite |
| Woofer brand | Custom-made |
| HF driver dimensions | 1 " |
| HF driver dimention (mm) | 25 mm |
| HF driver magnet | Ferrite |
| HF driver brand | Custom – made |
| System rating (RMS) | 80 W |
| Dispersion (H x V) | 60 x 60 ° |
| Frequency response | 50 – 20000 |
| Controls | mains switch (on/off), volume |
| Max. SPL | 114 dB |
| Indicators | overload, Power |
| Line input connectors | 6.3 mm jack, XLR |
| Line output connectors | XLR |
| Power supply | transformer |
| Cabinet surface | texture paint |
| Cabinet material | 12 mm MDF |
| Cabinet construction | Bass Reflex |
| Width | 274 mm |
| Height | 410 mm |
| Depth | 243 mm |
| Weight | 8,5 kg |
| Protection circuits | HF Driver, Over Volatge |
| Power amplifier (Class A) | Class A/B |
| Operating voltage | 220 V AC – 240 V AC, 50-60 Hz |
