REFERENCE MONITOR

Flax membranes on the woofers, an aluminum-magnesium “M” profile tweeter, three Class AB amplifiers, two 21 cm passive radiators: Shape Twin is a work tool with a vast and precise stereophonic image. A must-have for any recording studio!

COMPACT DESIGN

Its compactness makes it easy to integrate, even in the smallest of spaces. Its 2.5-way d’Appolito design offers a decisive advantage in terms of bass and low-midrange register control, always critical in a small space. This monitor expresses its full potential from a listening distance of 1 m.

A massive production weapon for professionals

FUNCTIONAL

XLR and RCA inputs, adjustable bass and treble levels, adaptable 160 Hz crossover, disengageable high-pass crossover are just some of the functions and settings available.

STYLE AND DISCRETION

Alongside an MDF cabinet body partly covered with real walnut veneer, Shape Twin is very stylish. Compact, it is as discreet as it is flexible in its positioning, thanks to the mounting inserts.

Specifications

Sound – Acoustics

• Product type : 2.5-way monitor
• Loudspeakers :
  • Woofer : 2 x 5″ Flax membrane
  • Tweeter : 1″ Aluminium-Magnisium M shaped dome
• Frequency response (+/- 3dB) :
  40 Hz – 35 kHz
• Maximum SPL (peak@1m) :
  110 dB

Sound – Electronics

• Inputs :
  • XLR: symmetrical 10 kOhms
  • RCA: asymmetrical 10 kOhms with compensanted sensitivity
• High frequency amplifier : 50 W, class AB
• Mid-range and low frequency amplifier : 2 x 80 W, class AB
• Indicators and controls :
  • HPF, LF Shelv, LMF EQ, HF Shelv

Design

• Height : 47.8 cm / 18.8 in
• Width : 21.1 cm / 8.3 in
• Depth : 27.9 cm / 11 in
• Weight : 11 kg / 24 lb
