Bring a tired pair of NS-10M “white cone” monitors back to life with a bolt-in crossover. The Avantone Pro AV10-MXO is a direct replacement crossover for the original Yamaha NS-10M studio monitors and Avantone CLA-10. Avantone reverse-engineered the original and rebuilt it with better-grade parts.
Why customers choose it
- Same sound as the original: the capacitors have the same values as the original circuit, and the inductors match the original in DC resistance, winding dimensions and value.
- Better parts: capacitors use a better grade of material and rating; the rear terminal plate uses a better grade of binding post.
- Stronger rear panel: aluminium instead of the original plastic, for more rigidity.
- Quick swap: ships with wires and spade connectors already connected, so you need minimal tools.
- Air-tight seal: a replacement gasket is included with every unit.
Who it is for
Studios and engineers who still mix on original Yamaha NS-10M “white cone” monitors, owners of Avantone CLA-10 monitors, and repair technicians who service these speakers.
What’s in the box
- AV10-MXO crossover with aluminium rear panel and binding posts
- Wires with spade connectors (pre-connected)
- Replacement gasket
Specifications
| Type | Replacement crossover for CLA-10 / Yamaha NS-10M |
|---|---|
| Musical power | 60 W |
| Maximum power | 120 W |
| Nominal impedance | 8 ohms |
| Rear panel | Aluminium with binding posts |
Good to know
- Fits the original NS-10M as a bolt-in part – no cabinet changes needed.
- Avantone also makes matching replacement drivers: AV10 MLF (woofer) and AV10 MHF (tweeter).
- If you are not comfortable working on speakers, have a technician fit it.
FAQ
Will it change the sound of my NS-10M?
Avantone says the circuit uses the same component values as the original, with inductors matched in DC resistance and winding, to keep the original sound.
