Studio sound plus built-in effects and MIDI – one small box for recording, producing and streaming. The Yamaha URX22C is a 2-in/2-out USB-C audio/MIDI interface with 32-bit/192 kHz resolution, two D-PRE mic preamps and an internal DSP for mixing and effects. It comes with Steinberg software and suits creators who record music, podcasts or live streams.
Why customers choose it
Who it is for
Home producers and singer-songwriters, guitarists who want amp simulation while recording, podcasters, and live streamers who want effects and mix control without extra hardware.
What’s in the box
- URX22C audio/MIDI interface
- Setup guide
- Cubase AI licence card
- Basic FX Suite licence card
- Steinberg Plus licence card
- USB cable (3.1 Gen1, Type-C to Type-A, 1.0 m)
Specifications
| Inputs | 2 x Mic/Line combo (XLR / 6.3 mm); Hi-Z switch on input 2 |
|---|---|
| Outputs | 2 x TRS line, 1 x headphones (15 mW + 15 mW @ 40 ohms) |
| MIDI | 1 IN / 1 OUT |
| USB | USB Type-C, 32-bit |
| Sampling rate | 44.1-192 kHz |
| Frequency response | +0.0/-0.4 dB (20 Hz – 22 kHz) |
| Dynamic range | Inputs 102 dB, main output 105 dB |
| THD | Inputs 0.003 %, main output 0.002 % (1 kHz) |
| Gain range | 54 dB |
| Mixing | 2 mono + 3 stereo loopback + 1 FX; 1 MIX + 1 streaming mix bus, 1 FX bus |
| DSP effects | Gate, Compressor, Sweet Spot Morphing Channel Strip, Guitar Amp Classics, Pitch Fix, Ducker, Multi-Band Compressor, Compander, Delay, REV-X |
| Power | USB bus power (USB 3.0) or DC IN; 5 V / 0.9 A, 4.5 W |
| Size (W x H x D) | 159 x 47 x 159 mm |
| Weight | 1.0 kg |
| Type | USB audio/MIDI interface |
| Resolution | 32-bit / 192 kHz |
| Connectivity | USB Type-C, MIDI IN/OUT |
| Loopback | Yes, 3-channel |
Good to know
- Yamaha states it is powered from a USB 3.0 port; on a USB 2.0 port an optional power supply is required.
- Effects and routing are set in Yamaha’s free dspMixFx software.
- You need a microphone, headphones or monitors and a computer, iPhone or iPad to use it.
FAQ
Can I use it for live streaming?
Yes. Loopback mixes computer audio with your mic, and there is a separate streaming mix bus.
Can I plug in a guitar?
Yes. Switch on Hi-Z for input 2. The DSP includes Guitar Amp Classics amp simulation.
Does it have MIDI?
Yes, one MIDI IN and one MIDI OUT.
