8-channel echo mixer with a built-in MP3 player and recorder. The Stranger SM80U is a 8-channel audio mixer from Indian maker Stranger. It adds an MP3 player with recording (USB / MMC card, LCD display and remote) to a simple echo mixer.
Why customers choose it
Who it is for
Small PA setups, jagrans and kirtans, shops, small halls, schools, home karaoke and practice rooms that need to mix a few mics and a music source.
Specifications
| Type | Audio mixer with digital echo and MP3 player |
|---|---|
| Channels | 8 |
| Inputs | Unbalanced mic and mono line |
| Mic Input Impedance | 2K ohms |
| Line Input Impedance | 10K ohms |
| Tone Control | Bass +/-16 dB, mid +/-10 dB, treble +/-16 dB |
| Digital Echo | 20 – 400 ms |
| Faders | 30 mm per channel |
| Frequency Response | 25 Hz – 20 kHz |
| Gain | -10 dB to -50 dB |
| S/N Ratio | 70 dB |
| Distortion | 0.01% |
| Effect Send | 5.5 V max |
| Effect Return | -30 dB max |
| MP3 Player | With recording, USB / MMC slot, LCD display, remote |
| Metering | Clip LED per channel, 10-segment LED main output |
| Power Supply | AC 220 V, 50 Hz (external adapter) |
Good to know
- Record the programme straight to a USB drive or MMC card.
- Inputs and outputs are unbalanced – keep cables short for the lowest noise.
- Uses an external power adapter (AC 220 V, 50 Hz).
