₹103,585
In stock
In stock
| Maximum input gain (Gain fcc) | 14.5 dBu |
|---|---|
| Input impedance | 10 kΩ |
| Frequency range (-3 dB) | 20 Hz – 200 kHz |
| THD + N (10 Hz – 22 kHz, 30 dB) | 0.003 % |
| Noise (A-weighted, 150 Ω, 30dB) | -94 dBu |
| E.I.N. (150 Ω) | -128 dBu |
| Common mode rejection (1 kHz) | 70 dB |
| Speaker Output A Maximum output gain | 22.5 dBu |
| Speaker Output A Output impedance (balanced) | 150 Ω |
| Speaker Output A Output impedance (unbalanced) | 75 Ω |
| Speaker Output A Volume control range | -78 dB – 0 dB |
| Headphone Amplifier Pin Wiring | Tip = L, Ring = R, Sleeve = GND |
| Headphone Amplifier Output impedance | 33 Ω |
| Headphone Amplifier Frequency range (-3 dB) | 10 Hz – 200 kHz |
| Headphone Amplifier Max output power (600 Ω) | 150 mW |
| Headphone Amplifier Max output power (300 Ω) | 265 mV |
| Headphone Amplifier Max output power (470 Ω) | 670 mW |
| Headphone Amplifier THD + N (10 Hz – 22 kHz, 0 dBu, 47 Ω) | 0,0026 % |
| Internal Power Supply Operating voltage for analog audio | +/- 17 V |
| Internal Power Supply Operating voltage for digital audio | +5 V, +3.3 V |
| Internal Power Supply Phantom power | + 48 V |
| Internal Power Supply Power consumption | 16.8 W |
