Features
- Speaker and input source selector providing a convenient centralized point for routing and listening to stereo sources over various monitor speakers.
- 3-way line level speaker selector providing A/B or A/B plus C switching.
- Three 2-track / Stereo Inputs can be used to connect DAT, CD, MINIDISK, sub-mixers, MIDI rigs or any other stereo line level source.
- Four stereo Source switches are used to route any of the connected stereo sources to the monitor output.
- Headphone Output with Level control for listening.
- Control Room VOLUME knob is used to adjust the overall level of the connected monitor speakers.
- SPEAKER 2 VOLUME control is used to level match SPEAKER 1 and SPEAKER 2 so that they are at the proper level when switched.
- Talkback Mic with momentary TALK switch and LEVEL control picks up conversation from the engineer and/or producer to talent over the CUE output.
- TALK TO CUE switch, when engaged, routes the internal TALKBACK microphone to the CUE output allowing the engineer and/or producer to talk to the talent on the other side of the glass.
- TALK TO 2-TR switch, when engaged, routes the internal TALKBACK microphone to the 2-track outputs allowing the engineer and/or producer to print a cue like “ soda jingle track seven” to the final two-track mix.
- Mono switch is used to check mixes for mono compatibility, and when engaged, all the input sources are summed to a mono signal.
- Mute switch provides a single button to silence all inputs and outputs.
- Dim switch, when engaged, will lower the level of all outputs by 20dB.
- Main Mix Stereo Input for connecting to main mixing console.
- Three speaker Outputs, one 1/4 inch balanced line level and two RCA unbalanced line level output.
- Four 2-track/Stereo inputs, three 1/4 inch balanced line level and one RCA unbalanced line level input.
