Complete Sound Solution

The LTX Series is a versatile collection of active and passive speakers, expertly crafted for both commercial and residential installations. Built into rugged plywood enclosures with elegant black or white finishes, these speakers combine strength with refined aesthetics, seamlessly blending into any environment without distraction.

Flexible Mounting Options

Every cabinet is equipped with multiple suspension points and dedicated accessories, giving you a wide range of installation choices. The KPTLTP bracket (included with LTX6 and LTX8) allows for wall and ceiling mounting with adjustable tilt and swivel orientations, ensuring even audience coverage. The C-shape brackets (for LTX10 and LTX12) provide discreet mounting on walls, ceilings, or stage structures. Plus, LTX8, LTX10, and LTX12 models include a pole adapter, enabling use as portable audio systems.

Uniform Sound Coverage

Designed for precision, the 90° x 90° symmetrical dispersion horns deliver consistent coverage in both horizontal and vertical setups. Whether installed in small venues or large halls, these horns ensure crystal-clear, low-distortion sound for every listener. Combined with high-excursion woofers and finely tuned vented cabinets, the LTX speakers produce extended frequency response with deep, tight bass.

Advanced Amplification Technology

The active LTX models are powered by cutting-edge Class D amplifiers with Switch Mode Power Supply, providing maximum power while minimizing weight and size. A sophisticated pre-amp section includes 24 dB/oct. phase-aligned crossovers, EQ filters for fine-tuning, and POWERCON connectors for reliable mains connection. Independent HF and LF limiter circuits protect the system while ensuring distortion-free sound, even at peak volumes.

Features

• 1” compression driver
• 8” woofer
• 90° H x 90° V coverage
• 160 W peak power handling
• Frequency response 70 Hz – 20 kHz
• SPL 1w/1m 92 dB
