Powerful Tone Customization

The Mooer Preamp Model X is designed for guitarists who demand precision, versatility, and ease when crafting their tone. With 14 preset slots and dual-channel support in each slot, players can store and access 28 customizable tones. Whether preparing for a live set or exploring a wide spectrum of sounds in the studio, the Model X provides immense tonal flexibility. Each preset is ready for real-time tweaking, allowing you to shape your tone exactly as you imagine.

Seamless Preset Navigation

Navigating your tones mid-performance is now effortless thanks to the expanded dual-footswitch layout. The Preamp Model X offers two convenient modes—preset scrolling and A/B channel switching—making it ideal for live use. A quick tap allows you to cycle through your saved tones or toggle between rhythm and lead settings instantly. This intuitive setup ensures you stay focused on your performance while having full control over your sound.

Editor Software & IR Support

The power of the Model X extends beyond the pedalboard. With Mooer’s editor software, you gain a complete desktop interface to manage presets, load impulse response (IR) files, and even update firmware. Model X supports not only Mooer’s MNRS, GIR, and GNR cab sim files, but also third-party IRs, allowing unlimited tone exploration. Easily download official IRs from Mooer Studio or bring your own library of sounds into the mix.

Features

• Dual-channel digital preamp pedal based on MOOER’s unique MNRS sampling technology
• Includes 14 preset slots that can store two different channel settings each
• Supports loading MNRS, GNR, and GIR files via MOOER STUDIO to expand your tonal palette
• Dual-footswitch controls for preset scrolling or A/B channel switching
• 3 global cabinet simulation files with support for loading third-party impulse response files or  GIR files
• Comes with specialized editor software for preset management, IR loading, and firmware updates

Specifications

• Input： 1*1/4” Monoaural jack (Impedance value: 1M ohms)
• Output: 1*1/4” Monoaural jack (Impedance value: 510 ohms)
• Num. of Preset Slot: 14
• Num. of Factory Amp Model: 28 (Can be replaced by imported GNR file)
• Num. of Factory Cab Sim: 3 (Global cab sim, can be replaced by imported GIR/IR file)
• IR Spec: 44.1kHz/24bit/1024points
• Power supply: 9V DV center negative (Please ensure the voltage value of power supply is not more than 9V, ensure the polarity is correct.)
• Current Draw: 300mA
• Dimension: 0.334kg
• Weight: 75mm(D)*115mm(W)*33mm(H)
• Accessories: Owner’s manual, USB TYPE-C to TYPE-A cable; DC 9V power supply, sticker.
