| Product Type: | Installation Loudspeakers |
|---|---|
| Type: | Wall-mounted Loudspeaker |
| Low/mid Woofer dimensions | 4 x 4 " |
| Woofer dimensions (mm) | 4 x 101 mm |
| Woofer magnet | Ferrite |
| Woofer brand | Custom-made |
| HF driver dimensions | 1 " |
| HF driver dimention (mm) | 25 mm |
| HF driver magnet | Ferrite |
| Load rating (RMS) | 200 W |
| Dispersion (H x V) | 120° x 30 ° |
| Protection circuits | HF Driver |
| Frequency response | 75 – 20000 |
| SPL (1W/1m) | 94 dB |
| Max. SPL | 114 dB |
| Impedance | 8 Ohm(s) |
| Loudspeaker inputs | 1 |
| Speaker input connections | Clamp connector |
| Speakers per amplifier channel (DSP44/45K) | 4 |
| Cabinet surface | texture paint |
| Cabinet material | 12 mm MDF |
| Cabinet construction | Closed |
| Width | 140 mm |
| Height | 670 mm |
| Depth | 155 mm |
| Weight | 8 kg |
| HF driver brand | Celestion |
