Mix your live show and record it in studio quality – on one desk. The Mackie Onyx16 is a 16-channel premium analog mixer with multitrack USB recording, SD card recording, Bluetooth and a digital effects engine. It is made for live sound, houses of worship, home recording and content creation.
Why customers choose it
Who it is for
Live bands, houses of worship, schools, clubs, conference rooms and home or project studios that record multitrack.
Specifications
| Type | Analog mixer with multitrack USB |
|---|---|
| Channels | 16 |
| Mic preamps | 12 x Onyx, up to 60 dB gain |
| Phantom power | 48V on all mic channels |
| EQ | 3-band Perkins: ±15 dB @ 80 Hz, mid ±15 dB sweepable 100 Hz – 8 kHz (mono channels) or @ 2.5 kHz (stereo channels), ±15 dB @ 12 kHz |
| Low-cut filter | 100 Hz, 18 dB/octave |
| USB interface | USB 2.0, 18×4, 24-bit, 44.1 / 48 / 96 kHz |
| SD card | Stereo record / playback, 24-bit / 96 kHz |
| Bluetooth | Streaming to a mixer channel |
| Monitor sends | 2 mon send outputs, plus FX send |
| Other outputs | Main outs (XLR and 1/4″), control room outs, headphones |
| Meters | 12-segment stereo |
| Frequency response | 20 Hz – 30 kHz (+0 / -1 dB) |
| Power | Universal 100-240V AC, 50-60 Hz, 45 W, IEC cord |
| Dimensions (H x W x D) | 137 x 475 x 356 mm |
| Weight | 7.1 kg (15.6 lb) |
| EQ | 3-band Perkins with sweepable mid |
| Recording | USB multitrack + SD card stereo |
| Connectivity | USB, Bluetooth, SD card |
| Effects | Built-in reverb, delay, chorus |
Good to know
- Universal internal power supply (100-240V) – no external adapter, works directly on Indian mains.
- No driver is needed on a Mac; Mackie provides a driver for Windows.
- Comes with recording software (Waveform OEM with the DAW Essentials plugin bundle).
- A rack ear kit for the Onyx16 is available from Mackie as an option.
FAQ
Can I record each channel separately?
Yes. Over USB the Onyx16 works as a 18×4 audio interface, so your computer receives separate tracks for multitrack recording.
Can I play music from my phone?
Yes. Pair your phone by Bluetooth and the audio streams to a mixer channel, which can go to the main mix and aux sends.
