Yorkville Sound EF15 Elite 15” Unpowered Loudspeaker

Yorkville Sound EF15 Elite 15” Unpowered Loudspeaker

258,123.00

In stock

SKU: SM-10338 Category: Brand:
Brand
JBL
System Type
Unpowered Loudspeaker
Power Rating
1400 W Peak (700 W Program)
Biampable
No
Nominal Impedance (Ohms)
Sensitivity (dB AT 1Watt/1m)
97 dB
Max SPL
128 dB Peak (125.5 dB Continuous)
Frequency Response (Hz +/- 3dB)
55 Hz - 18 kHz
Crossover Frequency
1900 Hz
HF Driver(s)
3" Voice Coil (1" Titanium Diaphragm)
HF Horn
ABS Plastic Custom Waveguide
HF Dispersion (°H x °V)
60° x 40°
HF Protection
3x SK3 Protection Bulbs
LF Driver(s)
15" (3" Voice Coil)
Inputs - 1/4 IN Jacks
2
Inputs - Speakon 4-pin
2
Bar Handles
2 (1 Left Side, 1 Right Side)
Flypoints
8 (2 Top, 2 Bottom, 2 Each Side), 2 Pullback
Flying Hardware
1/4 - 20
Pole Mount Adapter (1 3/8
1 (Bottom)
Enclosure Materials
15 mm (5/8") 11-ply Russian Birch
Grille
Perforated Metal
Covering / Finish
Black Ultrathane Paint
Dimensions (DWH)
14" x 18.5" x 30" (35.5 cm x 47 cm x 76 cm)
Weight
61 lbs / 27.8 kg
    Support

    Our expertly trained sales engineers are ready to help!

    EF15

    Elite 15” Unpowered Loudspeaker

    The EF15 is a 15-inch 2-way passive loudspeaker that brings the sound, performance, and reliability of the Elite series to installations and venues that already have power amplifiers.

    Made with premium components, the EF15 is rated for 1400 watts of peak power (700 watts program) at 8 ohms, and the rear panel has 1/4″ and Speakon™ inputs.

    The cabinet offers durable birch construction, and the total weight is less than 65 pounds so the EF15 is easy to transport and stack.

    The EF15 is the largest and loudest passive speaker in the Elite range. Need something smaller? 10-inch (EF10) and 12-inch (EF12) versions are also available.

    Features

    • 1400 W Peak Power (700 W Program)
    • 15” Woofer with 3” Voice Coil
    • 3” Compression Driver
    • ABS-Coated Birch Plywood Construction
    • Made In Canada
    Brand

    JBL

    System Type

    Unpowered Loudspeaker

    Power Rating

    1400 W Peak (700 W Program)

    Biampable

    No

    Nominal Impedance (Ohms)

    Sensitivity (dB AT 1Watt/1m)

    97 dB

    Max SPL

    128 dB Peak (125.5 dB Continuous)

    Frequency Response (Hz +/- 3dB)

    55 Hz – 18 kHz

    Crossover Frequency

    1900 Hz

    HF Driver(s)

    3" Voice Coil (1" Titanium Diaphragm)

    HF Horn

    ABS Plastic Custom Waveguide

    HF Dispersion (°H x °V)

    60° x 40°

    HF Protection

    3x SK3 Protection Bulbs

    LF Driver(s)

    15" (3" Voice Coil)

    Inputs - 1/4 IN Jacks

    2

    Inputs - Speakon 4-pin

    2

    Bar Handles

    2 (1 Left Side, 1 Right Side)

    Flypoints

    8 (2 Top, 2 Bottom, 2 Each Side), 2 Pullback

    Flying Hardware

    1/4 – 20

    Pole Mount Adapter (1 3/8

    1 (Bottom)

    Enclosure Materials

    15 mm (5/8") 11-ply Russian Birch

    Grille

    Perforated Metal

    Covering / Finish

    Black Ultrathane Paint

    Dimensions (DWH)

    14" x 18.5" x 30" (35.5 cm x 47 cm x 76 cm)

    Weight

    61 lbs / 27.8 kg
