₹155,375
In stock
In stock
The Channel One is the ideal channel strip for reliable results with the highest sonic demands. Extensive automation for fast operation and musical sound characteristics guarantee first-class recordings from the first take.
| Microphone Input Maximum input gain (Gain fcc) | 14.5 dBu |
|---|---|
| Microphone Input Input impedance | 10 kΩ |
| Microphone Input Frequency range (-3 dB) | 20 Hz – 200 kHz |
| Microphone Input THD + N (10 Hz – 22 kHz, 30 dB) | 0.003 % |
| Microphone Input Noise (A-weighted, 150 Ω, 30dB) | -94 dBu |
| Microphone Input E.I.N. (150 Ω) | -128 dBu |
| Microphone Input Common mode rejection (1 kHz) | 70 dB |
| Instrument Input Maximum input gain (Gain fcc) | 24 dBu |
| Instrument Input Input impedance | 1,1 MΩ |
| Instrument Input Frequency range (-3 dB) | 20 Hz – 200 kHz |
| Instrument Input THD + N (10 Hz – 22 kHz, 1:1 Gain) | 0.005 % |
| Instrument Input Noise (A-weighted, 1:1 Gain, 100 Ω) | -89 dBu |
| Maximum input gain | 22.5 dBu |
| Input impedance (balanced) | 20 kΩ |
| Input impedance unbalanced) | 10 kΩ |
| Frequency range (-3 dB) | 10 Hz – 200 kHz |
| THD + N (10 Hz – 22 kHz, 0 dBu) | 0.002 % |
| Noise (A-weighted, 600 Ω) | -95 dBu |
| Common mode rejection (1 kHz) | -60 dBu |
| Internal Power Supply Operating voltage for analog audio | +/- 17 V |
| Internal Power Supply Operating voltage for digital audio | +5 V, +3.3 V |
| Internal Power Supply Phantom power | + 48 V |
| Internal Power Supply Power consumption | 16.8 W |
| External Power Supply AC/DC switching adapter | Mean Well GE18/12-SC |
| External Power Supply DC plug | (+) pin 2.1mm; (-) outside ring 5.5mm |
| External Power Supply Input voltage | 100 – 240 V AC; 50 – 60 Hz; 0.7 A |
| External Power Supply Output voltage | 12 V DC; 1.5 A |
