Samson TPI25 25′ Instrument Cable

Brand:  Samson
SKU: SM-8235

Product Highlights

Tourtek Pro TPI/TPIL Instrument Cables are designed to withstand the demands of sound engineers and touring musicians. Constructed with 99.99% OFC (Oxygen Free Copper), Tourtek Pro low-capacitance cables provide consistent performance while delivering uncolored sound from the audio source. Each cable features 99% braided shield coverage and carbon-impregnated conductive PVC insulation, offering extremely low noise and excellent rejection of RF/EMI interference. Finally, Tourtek Pro cables include heavy-duty, black-chrome-plated brass connectors with 24k gold-plated plugs and durable, thick PVC outer jackets, resulting in premium, rugged cables for any sound reinforcement application.

4,120

Out of stock

Features

  • Constructed with 99.99% Oxygen Free Copper (OFC) conductors for increased conductivity and resistance to corrosion.
  • Gold-plated contacts for clean signal transmission and prevent signal degradation.
  • 99% braided shield and carbon-impregnated conductive PVC insulation for low noise and excellent rejection of RF/EMI interference.
  • Heavy-duty black chrome-plated brass connectors with gold-plated plugs for durability and ruggedness in any sound reinforcement application.
  • Available in 10′, 20′, and 25′ lengths with 1/4″ or 1/4″ straight to right angle connectors.
Brand

Samson

Conductor AWG Size & Stranding

20 AWG / 0.10×65

Conductor Capacitance Conductor to Shield

28.7pF/ft @1kHz

Conductor Material

99.99% Oxygen Free Copper

Insulation Material

Polyethylene

Insulation Diameter

2.8mm ±0.05mm

Braided Shield Material

Bare Annealed Copper

Braided Shield Coverage

99%

Jacket Material

PVC, Matte Finish

Jacket Diameter

7.5mm ±0.1mm
