The RSXM10a is a compact active loudspeaker designed to provide powerful, exceptional monitoring for front-of-house engineers, live sound professionals, musicians, and DJs. The 10″ coaxial speaker with 1″ horn-loaded tweeter provides wide coverage, while the ultra-efficient 800-watt Class D amplifier provides plenty of headroom for even the loudest stages.
The RSXM10a produces 800 watts of Class D power through its 10″ woofer and premium 1″ horn-loaded tweeter. A compact, coaxial design gives the monitor amazing portability with impeccable sound. In addition, the RSXM10a features an integral 1 3/8″ pole mount and a Monitor/FOH optimization switch for added flexibility.
Multi-Talented Monitor
Designed to bring professional performance to a variety of monitoring applications, including keyboards and electronic drums, the RSXM10a is also convenient for DJs who need a dedicated monitor while working in a compact booth. A single XLR-1/4″ combo input is provided, along with an XLR link output for system expansion. In addition, the RSXM10a features a powder-coated steel grille and two integrated side carrying handles, making it durable yet highly portable for use on the road.
Features
Lightweight Class D 2-way active stage monitor
800 watts of output power
All-wood cabinet construction
Compact, coaxial design
10″ low frequency driver
1″ tweeter
XLR-1/4″ combo input
XLR Link output
Dedicated Volume knob
FOH/Monitor selector switch to optimize sound
1 3/8″ pole mount receptacle
Integrated side carry handles
Perforated steel grill protects all monitor components
Durable black, textured paint finish
Brand
Samson
Low Frequency
10” (254 mm) woofer with 2” (51 mm) voice-coil
High Frequency
1” (25.4 mm) Driver with 1” (25.4 mm) voice-coil
Frequency Response (-3 dB)
60 Hz to 20 kHz
Maximum SPL (Peak Power)
125 dB SPL @ 1 m
Coverage Angle (Horz. x Vert.)
70° x 70°
Equalization Switch
Monitor, FOH (Front of House)
Crossover Type
12 dB/oct
Crossover Frequency
3.5 kHz
Inputs
Balanced XLR & 1/4” Connectors
Output
Balanced XLR Line Output
Mounting Method
Integral 1 3∕8” Pole Mount Receptacle
Dimensions
14.27” x 13.8” x 12.87” / 362.5mm x 350.6mm x 327mm
