Premium Value For Live Mixing
The MXP144FX features premium circuitry specifically designed to work with Samson’s MDR (Maximum Dynamic Range) mic preamps to provide a wide frequency range, definitive channel separation and natural response. This ensures that all your mixes originate from pure, authentic audio signals, making the MXP144FX perfect for education, broadcast, band rehearsals, and other live sound applications.
Upgrade Your Mixes
With 100 low-noise, 24-bit digital effects, the MXP144FX offers a studio-inspired effects processor to add a professional touch to your mixes. The mixer also features a high-integrity, bi-directional USB connection for recording a mix into your favorite DAW or incorporating digital music files from your computer into a project.
Compact Powerhouse
The MXP144FX features six MDR mic preamps, with four channels equipped with single-knob compressors for studio-quality dynamic control without the need for constant tweaking of external gear. All channels on the MXP144FX are controlled by precision 60mm faders and feature 3-band EQ, gain trim, high-pass filter, and mute switch. In addition, each channel of the MXP144FX has a pre-fader aux send for your monitor mix and a post-fader aux send for routing external effects. Exceptional output flexibility makes the MXP144FX a worthy companion no matter the size of your venue, giving you precise fader control over your main mix (XLR and 1/4″ outputs), as well as a Mix 2 output, headphone (phones) monitoring with level control, and an RCA tape output for recording your performance.
Bringing Your Sound to Life
The MXP144FX features selectable 48V phantom power, so you can mix in the warm, natural response of your favorite condenser mics. For live performance, the MXP144FX features brightly colored knobs and an 8-segment LED level meter for safe and efficient operation in dark environments.
Portable, easy to use, and packed with features that ensure optimal control over your performance, the Samson MixPad® MXP144FX represents a new era of possibilities for affordable live mixers.
Features
- Ultra-low noise, high headroom analog mixer
- Six Class A, MDR (Maximum Dynamic Range) mic preamps
- Four stereo channels with multiple input options (1/4” and RCA)
- High-integrity, bidirectional USB interface
- 100 24-bit, low-noise digital effects
- Four TRS inserts for external signal processing
- 3-band active EQ
- High-quality, precision 60mm faders
- Four single-knob, studio-quality compressors
- Pre-fader Aux Send for monitor mix
- Post-fader Aux Send for external effects
- All mic channels equipped with input Gain and high pass filters
- 48V Phantom Power for condenser microphones
- Multiple outputs: Main Mix, Mix 2, Phones and Tape
- XLR and 1/4″ Main Mix outputs
- USB/Tape inputs assignable to Main Mix or Mix 2/Phones outputs
Specifications
| Mic to Main | 20Hz~30KHz |
|---|---|
| Line to Main | 20Hz~30KHz |
| Aux Return to Main | 20Hz~30KHz |
| Line to Aux Send | 20Hz~30KHz |
| Mic/Line to Main (Mono Ch) | <0.03% |
|---|---|
| Line to Main (Stereo Ch) | <0.03% |
| Line to Aux Send | <0.03% |
| Mic (Trim @ Min﹐ Fader set ”0”) | < -90dB 20HZ~30KHZ A-weighted |
|---|---|
| Line (Trim @ Min﹐ Fader set ”0”) | < -90dB 20HZ~30KHZ A-weighted |
| Mic to Main (bal) | 70dB |
|---|---|
| Line to Main (bal) (Mono Ch) | 43dB |
| Line/Tape to Main (Stereo Ch) | 33dB |
| Aux Return to Main | 25db |
| Mic to Aux Send | 75dB |
| Line to Aux Send (Stereo Ch) | 30dB |
| Main (All fader min) | -100dBu A-weighted |
|---|---|
| Aux Send (All fader min) | -105dBu A-weighted |
| Ch vs. Ch (Trim @ min﹐Fader set 0) | >75dB A-weighted |
|---|---|
| Input vs. Output | >60dB A-weighted |
| Mic Input (Mono Ch) | +16dBu |
|---|---|
| Line Input (Mono Ch) | +40dBu |
| High | ±15 dBu |
|---|---|
| Mid | ±15 dBu |
| Low | ±15 dBu |
| Mic (Mono Ch) | +16dBu |
|---|---|
| Line (Stereo Ch) | +16dBu |
| Phantom Power | 48V±3V |
|---|---|
| Headphone output (600 ohm load) | +20dBu |
| Internal DSP Effects | 100 presets |
| USB Bus Power | USB2.0 +5V DC 0.5A max |
| Dimensions (W x D x H) | 15.3” x 14.5” x 3.9” / 391mm x 370mm x 100mm |
| Weight | 8.3lb / 3.8kg |
