FOCAL TECHNOLOGIES

Beryllium inverted-dome tweeter, “W” diaphragm for woofer and subwoofer, TMD® suspension, large laminar air vent, IAL: Trio6 incorporates Focal’s best innovations. The sound is remarkably neutral throughout the spectrum, with a precise midrange, impactful bass and excellent dynamics with very low distortion.

DUAL FOCUS MODE

A highlight is the Focus Mode, which lets you switch from a 3-way to a 2-way monitor, offering a different speaker configuration at the touch of a pedal. Trio6 features a dual Focus Mode for extreme versatility: a 3-way monitor, a 2-way monitor (midrange and tweeter) and a 1-way full-range monitor (midrange only).

REINFORCED CABINETRY

The ST6 cabinets are made of thick, sturdy MDF and feature internal reinforcements to provide damping and rigidity, while limiting vibration and therefore distortion.

Specifications

Sound – Acoustics

• Product type : 3-way monitor
• Loudspeakers :
  • Subwoofer : 8″ W membrane
  • Woofer : 5″ W membrane
  • Tweeter : 1″ Beryllium inverted dome
• Frequency response (+/- 3dB) :
  • 3-way mode: 35 Hz – 40 kHz
  • 2-way mode (Focus): 80 Hz – 20 kHz
  • 1-way mode (Focus): 100 Hz – 15 kHz
• Maximum SPL (peak@1m) :
  115 dB

Sound – Electronics

• Inputs :
  XLR: symmetrical 10 kOhms
• High frequency amplifier : 50 W, class AB
• Mid-range and low frequency amplifier : • Bass : 100 W, class G • Midrange : 100 W, class G
• Indicators and controls :
  • Sensitivity
  • Auto standby
  • HPF, LF Shelv, LMF EQ, HF Shelv
  • Focus Mode

Design

• Height : 53.7 cm / 20.86 in
• Width : 29.2 cm / 11.41 in
• Depth : 36.9 cm / 14.52 in
• Weight : 25 kg / 55.12 lb
