An essential tool for recording producers and sound engineers who are looking to expand their connectivity without unnecessary complexity or expense, the Arturia AudioFuse X8 Out provides eight additional analog line outputs via ADAT to an existing ADAT-equipped audio interface. Achieve full Dolby ATMOS 9.1.6 by connecting AudioFuse X8 Out with an AudioFuse 16Rig interface.
The AudioFuse X8 OUT is an essential tool for recording producers and sound engineers who are looking for additional high-quality analog outputs. By improving integration with external gear and supporting complex signal routing for live setups, AudioFuse X8 OUT ensures studios can manage intricate audio workflows without the added complexity or cost.
More specifically, an 8 ADAT-to-Analog output expander enables you to send audio to outboard gear (hardware FX, mixing console…), add additional speakers, and control an array of synths via DC-coupled output.
Efficient Expansion
AudioFuse X8 OUT provides 8 outputs via ADAT, enhancing the connectivity of your existing audio setup without the unnecessary cost and clutter of a fully-featured audio interface.
Professional Audio Quality
AudioFuse X8 OUT supports 8 channels of premium ADAT-to-analog conversion up to 96 kHz and utilizes the best components available, ensuring your recordings and outputs maintain the highest fidelity.
Versatile Installation
Designed as half-sized rack units, X8 OUT comes with removable rack ears for flexible installation. This allows them to be used as desktop units or mounted in a standard rack setup, accommodating up to two units side by side for expanded setups.
Durable Construction
AudioFuse X8 OUT is built to withstand the rigors of studio and live use with simple front panel controls and robust power and TRS output sockets.
FEATURES
| Form Factor | Desktop (Rack-Mountable with Included Hardware) |
|---|---|
| Converter Type | D/A Converter |
| Number of Channels | 8x D/A (at 96 kHz) |
| Conversion Formats | ADAT |
| Display | No |
| Maximum Sampling Rate | 96 kHz / 24-Bit |
| Number of Microphone Inputs | No Mic Inputs |
| Analog Audio I/O | 8x 1/4" TRS Balanced Line Output |
| Phantom Power | No |
| Digital Audio I/O | 2x Mini-TOSLINK / 3.5 mm Optical ADAT Input (S/MUX Support) |
| Host Connection | No |
| Sync I/O | 1x BNC Clock Input |
| Network I/O | No |
| MIDI I/O | No |
| Expansion Slots | No |
| Wireless | No |
| Frequency Response | 20 Hz to 20 kHz ±0.04 dB (Minimum Gain) |
| Maximum Output Level | Outputs: |
| Impedance | 240 Ohms (Balanced) |
| Dynamic Range | 120.5 dBA |
| THD+N | -106 dB |
| Sample Rates | 44.1 to 96 kHz |
| Sample Rate Conversion | No |
| Bit Depths | 24-Bit |
| Sync Sources | ADAT, Word Clock |
| Power Requirements | AC/DC Power Adapter (Included) |
