Complete Cab Sim Solution

The Mooer RADAR is a powerful speaker simulator pedal designed to deliver authentic cabinet tones from a compact enclosure. Featuring 30 different speaker cabinet models, it replicates a full amplifier stack at the tail end of your pedalboard. It’s perfect for players who want to capture the full tone of their pedal chain without relying on bulky amps. RADAR is equally effective for live gigs, recording sessions, or headphone practice, thanks to its high-resolution 24-bit processing. Whether you’re sending your tone to a mixing console or DAW, Mooer RADAR ensures professional-grade output with pristine audio clarity, dynamic response, and unmatched convenience.

Studio-Grade Sound Tools

Beyond cab simulation, the RADAR includes 11 microphone models and 4 power amp simulations, giving players granular control over their tone. With adjustable microphone position and a customizable EQ stage, you can recreate virtually any amp sound or acoustic space. The unit also supports loading custom impulse responses (IRs), allowing you to personalize your tone to your exact liking. With the ability to store and recall up to 36 user presets, you can quickly toggle between different setups for various genres or songs. The RADAR bridges the gap between pedalboard simplicity and studio-grade sound shaping, all from a single, compact pedal.

Connectivity and Versatility

The Mooer RADAR is built for modern players who demand flexibility. It offers both 1/4” mono and 1/8” stereo outputs, making it ideal for plugging into headphones, audio interfaces, or PA systems. The built-in USB connection lets you link the pedal to a PC editor for deep editing and IR management. With a 100dB signal-to-noise ratio and a wide frequency response of 20Hz to 20kHz, the RADAR delivers crystal-clear, detailed audio across the full sonic spectrum. Its road-ready design, 300mA power requirement, and lightweight frame (just 150g) make it the ultimate travel companion for any serious guitarist.

Features

• 30 different speaker cab models
• 11 mic models
• 4 power amp models
• Customizable EQ stage
• Capable of loading custom IRS
• Store and recall up to 36 user presets
• Connect to PC editor via USB
• Supports headphones and lineout

Specifications

• Input : 1/4” mono audio jack.(Impedance: 100kΩ)
• Output : 1/4” mono audio jack (Impedance: 470Ω)
• 1/8” stereo audio jack (Impedance: 10Ω)
• Sampling rate : 44.1K
• Sampling accuracy : 24bit
• Signal to noise ratio : 100dB
• Frequency Range : 20Hz~20KHz
• Power requirements : 12V DC Only use the power supply provided
• Current Draw : 300mA
• Dimensions : 93.5mm(D) x 42mm(W) x 52mm(H)
• Weight : 150g
