Dependable Crown power for small PA systems, bands and DJs. The Crown XLi 800 is a two-channel power amplifier rated 300 W per channel into 4 Ω. Crown builds the XLi Series for musicians, DJs, entertainers, places of worship, discos and pubs, and recommends it for portable PA.
Why customers choose it
Who it is for
Bands and solo performers, DJs, small events, churches and temples, cafes, pubs and small halls that need a reliable amplifier for passive speakers.
Specifications
| Channels | 2 |
|---|---|
| Power at 4 Ω | 300 W x 2 |
| Power at 8 Ω | 200 W x 2 |
| Bridged 8 Ω | 600 W |
| Frequency response (1 W) | 20 Hz – 20 kHz, +0/-1 dB |
| THD | < 0.5%, 20 Hz – 20 kHz |
| IMD | ≤ 0.35% |
| Signal-to-noise ratio | > 100 dB (A-weighted) |
| Damping factor (8 Ω) | > 200 |
| Voltage gain | 29 dB |
| Input sensitivity | 0.775 V or 1.4 V |
| Input impedance | 20 kΩ balanced, 10 kΩ unbalanced |
| Inputs | XLR, RCA |
| Outputs | Speakon, binding posts |
| Cooling | Forced air |
| Dimensions (W x H x D) | 48.3 x 8.9 x 31.5 cm |
| Weight | 11.4 kg |
| Type | Power amplifier |
| Modes | Stereo, parallel, bridge-mono |
| Protection | Shorts, no-load, on/off thumps, RF |
Good to know
- Crown lists 230-240 V, 50/60 Hz among the mains versions – check the label on the rear panel.
- Speakers are not included; match speaker impedance and power to the figures above.
- The XLi 800, 1500, 2500 and 3500 are identical except for output power – step up to the XLi 1500 if you need more.
FAQ
Can I run one speaker from both channels?
Yes, in bridge-mono mode it gives 600 W into one 8 Ω speaker.
Can I connect a phone or laptop?
Yes, through the RCA inputs; set input sensitivity to suit the source.
